Newly Added Transpak TP-733VTSP Fully Automatic Pallet Strapping Machine with Compression

Transpak TP-733VTSP Fully Automatic Pallet Strapping Machine with Compression

New

Fully automatic top-seal pallet strapping machine with up to 2,500 kg compression. Available with single or two-head configurations for efficient vertical strapping of palletized loads.

More details

Transpak TP-733VTSP Fully Automatic Pallet Strapping Machine with Compression

12

3

0

0

model: tp-733vtsp-s-single-head

12

3

0

0

model: tp-733vtsp-t-two-heads

12

3

0

0

arch-size: 1600-2050-mm

12

3

0

0

arch-size: 1600-2450-mm

12

3

0

0

arch-size: 1600-2850-mm

12

3

0

0

arch-size: 2000-2050-mm

12

3

0

0

arch-size: 2000-2450-mm

12

3

0

0

arch-size: 2000-2850-mm

12

3

0

0

arch-size: 2400-2050-mm

12

3

0

0

arch-size: 2400-2450-mm

12

3

0

0

arch-size: 2400-2850-mm

12

3

0

0

$ 117,800.00

  Add to my wishlist

Reliable automatic pallet strapping with compression

The Transpak TP-733VTSP Series is a fully automatic top-seal pallet strapping system designed to secure palletized loads for safe handling and transportation. With adjustable compression up to 2,500 kg, it is particularly suited for applications where loads need to be compressed and securely strapped.

The series is available in two configurations: TP-733VTSP-S with one fixed strapping head and one strap guide, and TP-733VTSP-T with two strapping heads and three strap guides.

An all-electric drive, friction-weld sealing and Siemens PLC/HMI provide precise operation and straightforward machine control. The system handles both PP and PET strapping and can process up to 120 pallets per hour, depending on the application.

Multiple arch sizes are available to suit different pallet dimensions and production requirements.

Technical Specifications
Models
TP-733VTSP-S / TP-733VTSP-T
Strapping Head
S: 1 fixed / T: 2 heads, 1 fixed + 1 movable
Strap Guides
S: 1 / T: 3
Capacity
Up to 120 pallets/hour
Strap Type
PP or PET
Strap Width
9, 12 or 15.5 mm
Strap Tension
1,100–3,200 N standard
Low Tension Option
200–1,200 N
Strap Core
Ø406 mm
Compression
Up to 2,500 kg
Arch Width
1600 / 2000 / 2400 mm
Arch Height
2050 / 2450 / 2850 mm
Standard Arch Size
W1600 × H2050 mm
Electrical Supply
220 / 380 / 400 / 415V, 50/60 Hz, 3PH
Sealing Method
Friction weld
Control System
Siemens PLC & HMI
Item Number
S: 41203160-A16.20 / T: 41203170-A16.20
